Norco Optic C AXS

Norco Optic C AXS
  • Color: Black/Chrome
Please select options
Sorry, this item is currently not available.


The Optic is an aggressive short-travel sled that absolutely rips on descents but can get back up without a gondola. With 125mm of DH-inspired rear suspension, and 140mm travel up front, the Optic embodies Norco's Ride Aligned technology to provide clarity when your vision starts to blur from the speed, or your over-active tear ducts.

- Optic Carbon 29" 125mm FT/6061 Alloy RT
- Ride Aligned Trail geometry based around 140mm short offset forks
- Slack 65 Degree HA
- Short seat tubes with long travel droppers
- Ride Aligned Suspension setup
- Updated Chainstay and Seatstay
- Stiffer, 180mm post mount brake, added heel clearance.
- Vittoria Mazza and Martello tires w/Graphene 2.0 Compound
- Stan's Tubeless Ready - Rims pre-taped, valves and sealant provided

- RIDE ALIGNED: The Optic uses Norco's Ride Aligned design system which matches each individual bike to the human who rides it, creating a customized platform that is both stable and balanced, allowing the rider to push harder.
- FINE TUNED REAR SUSPENSION: We created the Optic's suspension design around a very specific spring curve and damper settings, and RockShox and Fox stepped up to build everything we were looking for.
- HIGH SPEED BY DESIGN: By relaxing the Optic's head angle to 65 degrees for stability, we fine-tuned the handling with reduced-offset forks – providing even more high-speed precision and predictability for a more aggressive trail attack.
- EQUIPPED TO DESCEND: To bolster the Optic's descending prowess, each bike is equipped with 4-piston disc brakes, shorter seat tubes, long-stroke dropper posts and aggressive knobby tires.


Frame Carbon Front Triangle/Aluminum Rear, 125mm Travel, Ride Aligned
Fork RockShox Pike Ultimate RC2, DebonAir, 140mm Travel, 42mm Offset
Headset FSA Internal Sealed Bearing
Rear Shock RockShox Super Deluxe Ultimate DH Custom RC, 190 x 45mm
Rims/Wheels Crank Bros. Synthesis E11 29" Carbon
Hubs Front: Industry Nine Hydra, 15 x 110mm Boost, 6-bolt
Rear: Industry Nine Hydra 12 x 148mm Boost, XD, 6 Bolt
Spokes Butted Stainless Black
Tires Front: Vittoria Mazza 2.4" Trail G2.0
Rear: Vittoria Martello 2.35" Trail G2.0
Crankset SRAM XX1 Eagle DUB SL, 170mm
Chainrings 32T
Bottom Bracket SRAM DUB PF92
Chain SRAM XX1 Eagle Rainbow
Rear Derailleur SRAM XX1 Eagle AXS
Cassette/Rear Cogs SRAM XG1299 Eagle Rainbow, 10-52T
Shifters SRAM Eagle AXS
Handlebars One Up Carbon, 800mm, 20mm Rise
Tape/Grips DMR Deathgrip
Stem OneUp EDC Compatible, 50mm Length, 35mm Clamp
Brake Levers SRAM Code RSC
Brakes SRAM Code RSC, 4 Piston w/SRAM Centerline 180mm, 6 bolt rotor
Pedals Sold Separately
Saddle Fizik Alpaca Terra, Wingflex
Seat Post RockShox Reverb AXS, 31.6mm, 125mm (S), 150mm (M,L), 170mm (XL)

* Subject to change without notice.

Part Numbers

Option UPC MPN
Black/Chrome / Small 058817483967 0640611904
Black/Chrome / Medium 058817483974 0640611905
Black/Chrome / Large 058817483981 0640611906
Black/Chrome / X-Large 058817484018 0640611907
